Hollow Metal Doors and Frames

Doors and Frames


Hollow metal doors are designed to meet architectural requirements for full flush doors. They combine the strength and dimensional stability of steel with structural integrity. The continuous bonding of core to metal provides an attractive, absolutely flat door, free of face welding marks. Tests have proven hollow metal doors are highly resistant to impact damage and offer low thermal conductivity.


  • Durable and easy to match to aesthetics of building
  • Manufactured for all wall conditions such as masonry, steel, stud, wood stud, and poured concrete


  • Lite kits and glazing available in standard and custom configurations with fire ratings up to 3 hours
  • Flush frames available in 18, 16, 14 and 12 gauge cold-rolled or galvannealed steel or 16 or 14 gauge stainless steel
  • Frames can be knocked down or welded at the miters and ground smooth
  • 12 gauge frames are saw miter welded or butt end welded corner construction only
  • Available for 1-3/8″ (35mm) or 1-3/4″ (44mm) thick doors
